GE IC698CHS117 Fail-Safe VME Rack for Industrial Control Reliability

Overview

GE IC698CHS117 Fail-Safe VME Rack for Industrial Control Reliability

The GE IC698CHS117 is a 17-slot VME backplane chassis engineered for the PACSystems RX7i platform — one of the most widely deployed fault-tolerant control architectures in continuous process industries. Designed to anchor mission-critical control cabinets in petrochemical, power generation, mining, water treatment, metallurgy, and port automation environments, the IC698CHS117 delivers the structural and electrical foundation that keeps safety interlocks, redundant I/O loops, and high-availability control strategies running without interruption.

In demanding industrial sites where electromagnetic interference, voltage transients, vibration, dust ingress, and high ambient temperatures are daily realities, the integrity of the rack chassis is the first line of defense. The IC698CHS117 provides a robust, surge-protected VME backplane that minimizes the risk of control interruption, spurious trips, signal drift, and unplanned shutdowns — protecting both personnel and production assets.

Fail-Safe Reliability Table

Control Cabinet Protection Strategy

A reliable control cabinet built around the IC698CHS117 chassis depends on a carefully selected ecosystem of modules working in concert. The IC698PSA350 power supply module provides stable, regulated DC power to the backplane, protecting all installed modules from voltage sags, surges, and ripple that are common in heavy industrial environments. Paired with the IC698CPE040 CPU module — GE’s high-performance PACSystems RX7i processor — the chassis supports deterministic scan times critical for safety interlock execution.

For analog process control loops where signal integrity is paramount, the IC698ALG232 analog input module delivers 16-channel, high-resolution measurement with built-in filtering to suppress noise from variable frequency drives and high-power switching equipment nearby. On the discrete side, the IC698MDL740 output module provides isolated 24VDC sourcing outputs capable of driving solenoid valves, motor starters, and safety relays without cross-talk or ground loop interference.

In applications requiring Profibus DP or Ethernet/IP communication to field devices, the IC698ETM001 Ethernet interface module integrates seamlessly into the RX7i backplane, enabling real-time data exchange with SCADA systems, historian servers, and remote I/O drops — all while maintaining deterministic control loop execution. For installations in hazardous areas or those requiring IEC 61511 functional safety compliance, the IC698CHS117 chassis serves as the backbone for redundant CPU configurations, where a secondary IC698CPE040 hot-standby processor ensures bumpless transfer in the event of a primary CPU fault, eliminating single points of failure in the control architecture.

Critical Industrial Safety Applications

Petrochemical & Refinery Plants: In continuous distillation, catalytic cracking, and compressor control applications, the IC698CHS117 anchors emergency shutdown (ESD) and burner management system (BMS) controllers. Its surge-protected backplane prevents spurious trips caused by high-energy switching transients from large motor loads, protecting both process continuity and personnel safety.

Power Generation & Substation Automation: Turbine governor control, excitation systems, and load dispatch automation demand zero-tolerance for control interruption. The RX7i chassis supports hot-standby redundancy configurations that maintain continuous control even during module replacement, enabling live maintenance without process shutdown.

Mining & Mineral Processing: Conveyor interlocking, crusher control, and flotation cell automation in underground and open-pit mines expose control hardware to extreme vibration, dust, and humidity. The IC698CHS117’s robust VME construction and sealed backplane connectors maintain reliable signal integrity in these punishing conditions.

Water & Wastewater Treatment: Pump station automation, chlorination dosing control, and SCADA-integrated monitoring systems rely on the RX7i platform for 24/7 unattended operation. The chassis supports long-term spare parts availability, ensuring that aging water infrastructure can be maintained without costly platform migrations.

Metallurgy & Steel Mills: Rolling mill drives, ladle furnace control, and continuous casting automation generate severe electromagnetic interference. The IC698CHS117’s EMI-hardened backplane design ensures that analog measurement accuracy and digital output reliability are maintained even adjacent to high-power induction heating equipment.

Port & Marine Automation: Crane control systems, ship-to-shore loaders, and vessel traffic management systems operating in salt-air, high-humidity coastal environments benefit from the IC698CHS117’s corrosion-resistant construction and wide operating temperature range, ensuring reliable year-round operation without derating.

Safety and Quality FAQ

Q1: What support terms coverage is provided with the IC698CHS117?
All IC698CHS117 units supplied by KNMKS carry a support terms confirmed by quotation from the date of shipment. This covers manufacturing defects, backplane connector failures, and functional performance under normal operating conditions. Support requests are processed with priority turnaround to minimize your site downtime.

Q2: What outgoing tests are performed before shipment?
Every IC698CHS117 chassis undergoes a comprehensive functional test protocol prior to dispatch. This includes backplane continuity verification, slot-by-slot module seating tests, power rail integrity checks, and visual inspection for physical damage. A test report is available upon request for quality-critical installations.

Q3: Is the IC698CHS117 compatible with all PACSystems RX7i CPU and I/O modules?
Yes. The IC698CHS117 is fully compatible with the complete GE PACSystems RX7i module family, including all IC698-series CPU, power supply, analog, discrete, and communications modules. It also supports mixed-slot configurations for redundant CPU and I/O architectures. If you require compatibility confirmation for a specific module combination, contact our technical team before ordering.

Q4: Can KNMKS guarantee long-term supply for ongoing maintenance and spare parts programs?
KNMKS maintains dedicated stock buffers for high-demand PACSystems RX7i components including the IC698CHS117, ensuring availability for planned maintenance shutdowns, emergency replacements, and multi-year spare parts programs. We support global distribution with regional fulfillment to minimize lead times for critical spare orders.
