Allen-Bradley 1336-MOD-KC005 Maintenance-Proven Spare Part for Factory Uptime

The Allen-Bradley 1336-MOD-KC005 is a dynamic brake kit option module designed for the 1336 PLUS series AC variable frequency drives operating in the 500–600V range. As a factory-original spare component sourced through verified industrial supply channels, this module plays a critical role in maintaining controlled deceleration performance, protecting drive hardware during regenerative braking events, and sustaining continuous production line availability in demanding manufacturing environments.

For maintenance engineers managing aging 1336 PLUS drive installations, the 1336-MOD-KC005 represents a direct-fit replacement that eliminates the need for drive-level reconfiguration. Its plug-in option module architecture allows field technicians to swap the brake kit during scheduled downtime windows without disturbing the main drive assembly, significantly reducing mean time to repair (MTTR) and minimizing unplanned production losses.

Procurement engineers sourcing spare parts for multi-drive control cabinets will find the 1336-MOD-KC005 a reliable stocking item. Given the extended service life of 1336 PLUS drives in legacy automation systems across automotive, material handling, HVAC, and process industries, maintaining at least one spare brake kit per critical drive reduces exposure to extended lead times on obsolete or end-of-life components.

Spare Maintenance Table

Maintenance Planning for Continuous Operation

When replacing the 1336-MOD-KC005 dynamic brake kit in a 1336 PLUS drive, a thorough site inspection of the surrounding electrical system is essential to prevent repeat failures and ensure full system restoration. Maintenance engineers should treat this replacement as an opportunity to audit the entire drive cabinet.

Begin by verifying the integrity of the 1336 PLUS main power supply module and confirming input voltage stability within the 500–600V specification. Unstable supply voltage is a leading cause of premature brake module stress. Next, inspect all drive input/output terminal blocks for signs of heat damage, loose connections, or corrosion — particularly on the DC bus terminals where the dynamic brake circuit interfaces with the drive.

Check the 1336-MOD-TA or 1336-MOD-TB analog I/O option modules if installed alongside the brake kit, as shared option slot configurations can affect thermal loading within the drive chassis. Inspect the 1336-BRF brake resistor assembly connected externally to the brake kit — a failed or degraded resistor is frequently the root cause of brake module damage and must be tested before installing a replacement 1336-MOD-KC005.

For drives integrated into a broader control system, verify the 1336-GM1 or 1336-GM2 communication gateway modules for parameter integrity after the swap, as some drive configurations store brake parameters in non-volatile memory that may require re-commissioning. If the drive is connected to a 1747 SLC 500 or 1756 ControlLogix PLC via DeviceNet or DH+, confirm that the drive’s node address and fault response parameters are correctly restored post-replacement.

Finally, inspect the control cabinet’s fusing and circuit protection — particularly the branch circuit fuses protecting the drive input — and verify that the cabinet’s thermal management (fans, filters, and ventilation clearances) meets the drive’s operating specifications. Overtemperature conditions accelerate brake module wear and are a preventable failure mode with proper cabinet maintenance.

Site Replacement Workflow

Step 1 — Isolate and de-energize: Follow LOTO (Lockout/Tagout) procedures. Disconnect main power and allow the DC bus capacitors to fully discharge (minimum 5 minutes after power-off, verify with a DC voltmeter before touching internal components).

Step 2 — Document existing configuration: Record all drive parameters using a connected PLC terminal or the 1336 PLUS HIM (Human Interface Module) before removal. Note the brake kit slot position and any jumper settings on the existing 1336-MOD-KC005.

Step 3 — Remove the failed module: Carefully extract the brake kit from its option slot. Inspect the slot connector for damage or contamination. Clean with dry compressed air if necessary.

Step 4 — Install the replacement 1336-MOD-KC005: Seat the new module firmly into the option slot. Verify that the module is fully engaged and that any retention clips or screws are secured per the 1336 PLUS installation manual.

Step 5 — Reconnect and verify: Restore power and perform a controlled deceleration test at reduced load before returning the drive to full production duty. Confirm that the brake chopper activates correctly and that no fault codes are generated on the drive display or PLC HMI.

Step 6 — Update maintenance records: Log the replacement date, part number, and post-installation test results. Schedule the next brake system inspection at the next annual maintenance interval.

This workflow supports a direct replacement of legacy brake kit variants within the 1336 PLUS platform, maintaining full system compatibility without firmware changes or drive reconfiguration in most standard installations.

Spare Parts Support FAQ

Q1: Is the 1336-MOD-KC005 compatible with all 1336 PLUS drive frame sizes?
The 1336-MOD-KC005 is designed for 1336 PLUS drives operating in the 500–600V input range. Compatibility with specific frame sizes depends on the drive’s horsepower rating and chassis configuration. Always cross-reference the drive’s catalog number and option module slot availability against the 1336 PLUS product selection guide before ordering. Our team can assist with compatibility verification prior to shipment.

Q2: How is the 1336-MOD-KC005 tested before shipment?
Each unit undergoes functional inspection and electrical verification prior to dispatch. We confirm module integrity, connector condition, and basic electrical continuity as part of our pre-shipment quality process. All units are shipped with a support terms confirmed by quotation covering manufacturing defects and functional failures under normal operating conditions.

Q3: Can you supply the 1336-MOD-KC005 for long-term maintenance contracts or annual stocking programs?
Yes. We support long-term spare parts supply agreements for maintenance teams managing multiple 1336 PLUS drive installations. Stocking arrangements, scheduled delivery, and priority allocation for critical spares are available. Contact our sales team to discuss volume requirements and lead time commitments.

Q4: What is the recommended spare parts strategy for 1336 PLUS drives in legacy systems?
For production-critical applications, we recommend maintaining a minimum of one 1336-MOD-KC005 brake kit per drive as an on-site cold spare, supplemented by a site-level stock of the associated brake resistor assembly and key I/O option modules. Given the end-of-life status of the 1336 PLUS platform, proactive stocking is strongly advised to avoid extended procurement lead times during unplanned failures.
