CYBOR 25823-18 Migration-Ready Bellows Pump for Legacy Systems

Overview

CYBOR 25823-18 Migration-Ready Bellows Pump for Legacy Control Systems

The CYBOR 25823-18 (also supplied as 25823-T4-18, part reference 5026-00 B1) is a migration-ready bellows pump engineered as a direct replacement for aging 25823 Series semiconductor fluid dispense systems. As OEM production of legacy dispense components enters end-of-life, facilities running photoresist, developer, and chemical dispense lines face mounting pressure to source verified drop-in replacements that preserve existing process parameters without triggering full system re-qualification. The CYBOR 25823-18 addresses this challenge with a form-fit-function compatible design that minimises retrofit scope and protects capital investment in installed dispense infrastructure.

Before committing to a replacement, engineers should confirm the following against their installed system: supply voltage and pump drive power capacity (typically 24 VDC or 100–240 VAC depending on controller generation), inlet/outlet port orientation and tubing OD (verify 1/4″ or 3/8″ PTFE or PFA line compatibility), dispense controller interface (analogue 0–10 V, digital I/O, or RS-232/RS-485 serial command set), stroke volume and dispense cycle timing stored in the host recipe, and mounting footprint and cabinet clearance within the dispense module enclosure. Where the original pump was paired with a CYBOR 25823 Series dispense controller or a third-party PLC-based sequencer, the replacement unit should be bench-tested against the existing command profile before installation to confirm stroke response and leak-check integrity.

Facilities upgrading from earlier-generation CYBOR pump assemblies often find that the 25823-18 can be installed alongside retained system components such as the CYBOR 25823 Series filter housing, existing PFA dispense nozzle assemblies, and the original pressure/vacuum sensor module without requiring re-routing of process lines. Where the legacy system included a CYBOR 5026-series pump driver board, compatibility should be verified against the driver firmware revision before power-up. In mixed-generation installations, engineers have also successfully retained the original CYBOR dispense arm and nozzle positioning assembly while replacing only the pump head, reducing retrofit time to under two hours per dispense station.

Migration Compatibility Table

Retrofit Planning for Existing Automation Systems

A successful retrofit of the CYBOR 25823-18 into a running semiconductor fab or chemical process line requires a structured pre-installation audit. Begin by documenting the existing dispense station layout: record the pump mounting orientation, the routing of inlet and outlet PFA tubing, and the position of the pressure/vacuum sensor module relative to the pump body. If the station uses a CYBOR 25823 Series filter housing upstream of the pump, inspect the filter element and replace it concurrently to avoid contaminating the new pump bellows with particulate from the legacy filter.

Next, audit the electrical interface. Identify whether the pump drive signal originates from a dedicated CYBOR 5026-series pump driver board, a PLC analogue output card, or a direct digital I/O module. Capture the current drive signal waveform and timing parameters from the host recipe before disconnecting the legacy pump. This data will serve as the baseline for post-installation validation. Where the dispense system communicates over RS-485 serial, confirm the baud rate, parity, and device address assigned to the pump channel — these settings must be preserved or re-entered in the replacement unit’s configuration register.

For facilities running multi-station dispense lines, consider staging the retrofit one station at a time to maintain production continuity. Retain the legacy pump as a tested spare during the initial commissioning period. Where the original system included a CYBOR dispense arm and nozzle positioning assembly, verify that nozzle height and dispense offset coordinates stored in the HMI recipe screen remain valid after pump replacement — bellows stroke volume consistency between the legacy and replacement unit should be confirmed with a gravimetric dispense test before returning the station to production. Additionally, if the line uses a CYBOR chemical supply module or centralised chemical distribution panel, confirm that back-pressure settings at the supply manifold are within the operating range of the 25823-18 to prevent bellows fatigue.

Downtime Control During System Migration

Minimising unplanned downtime during a bellows pump replacement is critical in semiconductor and precision chemical process environments where dispense interruptions directly impact yield. The CYBOR 25823-18’s form-fit-function compatibility with the 25823 Series platform means that mechanical swap time is typically under 30 minutes per station when the replacement unit is pre-staged and the process line has been properly depressurised and purged.

To protect the original process logic, export and archive the full dispense recipe set from the host controller or HMI before beginning any hardware work. If the system uses a PLC-based sequencer, back up the ladder logic program and any associated data tables. This ensures that in the unlikely event of a controller communication fault during pump swap, the original program can be restored without re-engineering. Where the dispense system is integrated into a broader fab automation network via RS-485 or discrete I/O, coordinate the maintenance window with the facility’s automation team to prevent upstream equipment from issuing dispense commands to an unpowered pump channel.

After mechanical installation, perform a controlled leak-check at operating pressure before resuming chemical flow. Run a minimum of five dry-cycle strokes to confirm bellows actuation, then execute a gravimetric dispense test at the target volume to validate stroke calibration. Document the post-installation dispense weight data alongside the pre-removal baseline to confirm process equivalence. This validation record supports change-control documentation requirements common in ISO- and SEMI-certified process environments. With proper pre-staging and a structured commissioning sequence, total controlled downtime for a single-station CYBOR 25823-18 retrofit can be held to under two hours, including purge, swap, leak-check, and dispense validation.

Retrofit Support FAQ

Q1: Is the CYBOR 25823-18 a direct drop-in replacement for the original 25823-18 and 25823-T4-18?
Yes. The 25823-18 and 25823-T4-18 share the same mechanical footprint, port interface, and drive signal compatibility as the original 25823 Series pump. No bracket modification or tubing re-routing is required in standard installations. Confirm the suffix variant (25823-18 vs. 25823-T4-18) against your system’s BOM before ordering.

Q2: What commissioning steps are required after installation?
After mechanical installation and leak-check, restore the original dispense recipe parameters from your archived backup. Run five dry-cycle strokes to confirm bellows actuation, then perform a gravimetric dispense test at the target volume. Verify that the dispense weight falls within ±2% of the pre-removal baseline. If the system communicates over RS-485, confirm the device address and baud rate settings match the host controller configuration.

Q3: How is the unit tested before shipment?
Each CYBOR 25823-18 unit undergoes functional actuation testing and leak integrity verification prior to shipment. Units are packaged in anti-static, moisture-barrier packaging suitable for cleanroom receiving inspection. A test report is available upon request for facilities with incoming inspection requirements.

Q4: What does the support terms confirmed by quotation cover, and what is your stock availability?
The support terms confirmed by quotation cover manufacturing defects in materials and workmanship under normal operating conditions. It does not cover damage caused by incompatible chemicals, improper installation, or operation outside specified parameters. Stock is maintained across regional distribution hubs to support fast global shipment. Contact our team for current lead time and quantity availability before placing a critical-path order.
